LGJ-20FD/30FD/50FD Commercial Coffee Food Vacuum Freeze Dryer
Fruits Freeze Drying Equipment
LGJ-10/12/18 Vacuum freeze dryers,small amount of samples can
pre-freeze in condenser.They are suitable for lab use or
small-scale production,and
they can meet requirements for most laboratories.
Types:A:standard type,B:top press type,C:manifold type,D:manifold
with top press type,E:T-type,T:T-type
Features:
■All-in-one structure,small size,no external flange,easy to use,no
leakage.
■The cold trap and console are made of stainless steel,which is
anti-comrosion and easy to clean.
■All materials in contact with the product use inert materials to
meet the requirements of the GLP.
■All stainless steel inflated/water release valve is designed and
produced by our Bonnin company,which is safety,anti-corrosion,no
leakage.
■ With sample pre-frozen function,large cold trap opening,no inner
coil,and low temperature refrigerator is needless.
■ Patented gas diversion technology,and strong ice holding ability.
■ World-known brand compressors,high efficiency,long life,low
noise.
■ Well-known brand vacuum pump with a high pumping speed to achieve
a higher ultimate vacuum.
■ Vacuum pump protection function can set the cold trap temperature
to protect the vacuum pump life.
■ Professionally designed FD-LAB freeze-drying machine control
system+SH-HPSC-I modular controller with high reliability and
stability.
■ Intelligent data recording system can real-time record and
display the cold trap temperature curve,sample temperature
curve,vacuum curve.
■ Cold trap electric heating defrosting function.
| Normal type | LGJ-10 | LGJ-12 | LGJ-18 | LGJ-10FD |
| Freeze-dried area | 0.12M2 | 0.12M2 | 0.18M2 | 0.2M2 |
| Number of plate | 4 | 4 | 6 | 2 |
| Plates space | 70mm | 70mm | 70mm | 70mm |
| Loadable material | 1.2L | 1.2L | 1.8L | 2L |
| Cold trap temperature | ≤-56℃ | ≤-56℃ | ≤-56℃ | -50—+70 electric heating |
| Water for cold trap | 3-4KG/24Hr | 3-4KG/24Hr | 6KG/24Hr | 3-5KG/24Hr |
| Voltage | AC220V/50Hz | AC220V/50Hz | AC220V/50Hz | AC220V/50Hz |
| Dimension | 15×450×(370+430) | 580×500×(720+430) | 630×580×(970+460) | 750*800*1300 |
| Normal type | LGJ-20F | LGJ-30F | LGJ-50F | LGJ-100F |
| Freeze-dried area | 0.3M2 | 0.4M2 | 0.5M2 | 1M2 |
| Number of plate | 3+1 | 4+1 | 4+1 | 6+1 |
| Plates space | 70mm | 70mm | 70mm | 70mm |
| Plate size | 270*400*15 | 300*340*15 | 360*480*15 | 360*480*15 |
| Plate temperature | -50℃ to 70℃ | -50℃ to 70℃ | -50℃ to 70℃ | -50℃ to 70℃ |
| Cold trap temperature | ≤-75℃ | ≤-75℃ | ≤-75℃ | ≤-75℃ |
| Water for cold trap | 4KG/24Hr | 6KG/24Hr | 8KG/24Hr | 15KG/24Hr |
| Defrost | electric defrost | Natural defrost | Natural defrost | electric defrost |
| Voltage | AC220V/50Hz | AC220V/50Hz | AC380V/50Hz | AC380V/50Hz |
| Dimension | 800*800*1550 | 880*735*1320 | 960*785*1450 | 1020*780*1700 |
FAQ 1. Are you a factory or trading company?
We are a factory.
FAQ 2. Can you supply OEM?
OEM is available.
FAQ 3. What's the MOQ ?
(1). MOQ is 1 piece. The disposable supplies order usually at least
1 box.
FAQ 4. How about the order processing and lead time?
After order confirmation and receive the advance payment, we will
prepare the machines and goods. Usually could ready within 10
working day, when dispatch, will inform client and send the
documents for client making import customs clearance.
FAQ 5. What quality will be ensured?
100% new and quality inspection before delivery from factory.
Stable export box for good package.
FAQ 6. Can you guide the working?
The machine will deliver with English display, English manual and
video for installation and operation.
FAQ 7. How can your engineer replace parts if they are not beside
the machine?
Bonnin’s engineer could provide the solutions by email and video.
In warranty period, we can send spare parts for free and life-time
technical support for spare supply.
